中华关节外科杂志(电子版) ›› 2026, Vol. 20 ›› Issue (04) : 452 -461. doi: 10.3877/cma.j.issn.1674-134X.2026.04.007

临床论著

骨水泥螺钉技术修复大骨节病胫骨平台缺损的疗效
刘刚, 王孟†(), 窦馥国, 高大龙, 董舒, 胡伟, 王洋, 张凯, 刘蔚
  1. 712000 陕西 咸阳,咸阳市中心医院运动及关节外科
  • 收稿日期:2025-08-27 出版日期:2026-08-01
  • 通信作者: 王孟
  • 基金资助:
    陕西省卫生健康科研基金(2022D004)

Efficacy of screw cement technique for tibial plateau defect reconstruction in Kashin-Beck disease

Gang Liu, Meng Wang†(), Fuguo Dou, Dalong Gao, Shu Dong, Wei Hu, Yang Wang, Kai Zhang, Wei Liu

  1. Sports and Joint Surgery Department of Xianyang Central Hospital, Xianyang 712000, China
  • Received:2025-08-27 Published:2026-08-01
  • Corresponding author: Meng Wang
引用本文:

刘刚, 王孟, 窦馥国, 高大龙, 董舒, 胡伟, 王洋, 张凯, 刘蔚. 骨水泥螺钉技术修复大骨节病胫骨平台缺损的疗效[J/OL]. 中华关节外科杂志(电子版), 2026, 20(04): 452-461.

Gang Liu, Meng Wang, Fuguo Dou, Dalong Gao, Shu Dong, Wei Hu, Yang Wang, Kai Zhang, Wei Liu. Efficacy of screw cement technique for tibial plateau defect reconstruction in Kashin-Beck disease[J/OL]. Chinese Journal of Joint Surgery(Electronic Edition), 2026, 20(04): 452-461.

目的

探讨骨水泥螺钉技术在大骨节病(KBD)膝关节置换术(TKA)中修复胫骨平台后内侧非包容性骨缺损的临床疗效。

方法

纳入2018年11月至2023年12月符合KBD诊断标准(WS/T 10026-2024)、保守治疗无效、伴胫骨平台后内侧非包容性骨缺损及内翻畸形,且无手术禁忌的TKA患者。排除膝部手术/骨折史、外翻或其他膝外畸形、影响功能的神经疾病及活动性感染者。按骨缺损深度分组:深度≤10 mm为浅缺损组,深度>10 mm为深缺损组。均采用螺钉骨水泥技术重建骨缺损。记录术前及末次随访的美国膝关节协会评分(KSS)、WOMAC评分、关节活动度(ROM)、X线片及胫股角(TFA),统计假体及螺钉使用情况。组内术前术后计量资料比较用配对t检验,组间疗效采用等效性检验,透亮线发生率用卡方检验。

结果

共48例患者(50膝),其中2例双膝,浅、深缺损组各25例。缺损深度分别为(6.4±2.9)mm和(15.1±3.2)mm;两组性别、年龄、身体质量指数差异无统计学意义(均为P>0.05)。随访时间浅缺损组(49±11)个月,深缺损组(54±18)个月。两组术后KSS临床(t=-37.516、-19.859)和功能评分(t=-110.667、-40.208)、WOMAC评分(t=19.105、11.941)及ROM(t=-33.963、-15.531)均较术前显著改善(均为P<0.001)。末次随访假体位置固定良好,无松动、移位;骨水泥-骨界面<2 mm透亮线共23例(浅8例、深15例),随访无进行性增宽,无假体下沉或骨溶解。两组术前TFA[(166.1±5.5)° vs(166.9±5.6)°]差异无统计学意义(P>0.05),术后均获得矫正(t=-8.229、-7.132,均为P<0.001);术后TFA两组间差异无统计学意义(P>0.05)。等效性检验显示两组术后临床疗效及下肢力线矫正效果具有等效性。

结论

骨水泥螺钉技术可有效修复KBD患者TKA术中胫骨平台后内侧非包容性骨缺损,恢复膝关节生物力学性能,短期随访固定可靠,且费用较低,适宜在KBD贫困人群中推广应用。

Objective

To investigate the clinical efficacy of the screwcement technique for reconstructing noncontained posteromedial tibial plateau bone defects during total knee arthroplasty (TKA) in patients with Kashin-Beck disease (KBD).

Methods

This study included patients who underwent TKA between November 2018 and December 2023 and met the following criteria: diagnosis of KBD according to the Chinese diagnostic standard (WS/T 10026—2024), failure of conservative treatment, presence of non contained posteromedial tibial plateau defects with varus deformity, and no contraindications to surgery. Exclusion criteria: knee surgery or fracture histories, valgus or other extra-articular knee deformities, neurological disorders affecting function, and active infection. Patients were stratified by defect depth: those with defects ≤10 mm were assigned to the shallow defect group, and those with defects >10 mm to the deep defect group. All the patients underwent bone defect reconstruction using the screw cement technique. Preoperative and final follow-up data were recorded, including the Knee Society score (KSS), Western Ontario and McMaster Universities osteoarthritis index (WOMAC) score, range of motion (ROM), radiographic findings, and tibiofemoral angle (TFA). Prosthesis implantation and the number of screws used were also documented. Paired t tests were used for within group comparisons between preoperative and postoperative continuous variables, equivalence testing was applied for intergroup efficacy comparisons, and chi square test was used to compare the incidence of radiolucent lines.

Results

A total of 48 patients (50 knees) were enrolled, including two patients with bilateral involvement. The shallow defect and deep defect groups each comprised 25 knees. The mean defect depths were (6.4±2.9) mm and (15.1±3.2) mm, respectively. There were no statistically significant differences in gender, age, or body mass index between the two groups (all P>0.05). The follow up duration was (49±11) months for the shallow defect group and (54±18) months for the deep defect group. Both groups showed significant improvements in KSS clinical (t=-37.516, -19.859) and functional scores (t=-110.667, -40.208) , WOMAC scores (t=19.105, 11.941) and ROM (t=-33.963, -15.531) after surgery (all P<0.001). At the final follow up, all prostheses were well fixed without loosening or migration. Radiolucent lines <two millimeters at the bone cement interface were observed in 23 cases (eight in the shallow defect group and 15 in the deep defect group), with no progressive widening during follow up and no cases of subsidence or osteolysis. TFA [(166.1±5.5)° vs (166.9±5.6)°] showed no statistically significant difference between groups before surgery (P>0.05). Compared with the data before surgery, TFA values were significantly improved in both groups after surgery (t=-8.229, -7.132, both P<0.001), with no statistically significant difference between two groups (P>0.05). Equivalence testing demonstrated that the postoperative clinical outcomes and correction of lower limb alignment were equivalent between the two groups.

Conclusions

The screw cement technique is a viable option for reconstructing non contained posteromedial tibial plateau defects in KBD patients undergoing TKA. It effectively restores knee biomechanical performance, provides reliable fixation in the short term, and is cost effective, making it particularly suitable for widespread application in the impoverished KBD affected population.

图1 患者术前大体像,示膝关节畸形严重。图A为站立正位;图B为术前站立侧位;图C为术前左侧屈曲位;图D为术前右侧屈曲位
Figure 1 General appearance of the patient before surgery, showing severe knee deformity. A is image of standing at anteroposterior view; B is image of standing at lateral view; C is image of left knee in flexion; D is image of right knee in flexion
图2 术前下肢X线片。图A为下肢全长显示双下肢呈内翻畸形;图B为右膝正侧位,示胫骨骨缺损16 mm;图C为左膝正侧位,示胫骨骨缺损14 mm
Figure 2 Radiographs of lower limbs before surgery. A is full-length anteroposterior view of the lower extremities, showing varus deformity of both lower limbs; B is anteroposterior and lateral view of the right knee, showing a tibial bone defect of 16 mm; C is anteroposterior and lateral view of the left knee, showing a bone defect of 14 mm
图3 右膝术中照片。图A为术中显露可见股骨内髁磨损严重,胫骨内侧平台缺损;图B~C为显示胫骨内侧平台骨缺损情况;图D为平台骨质缺损处使用螺钉栽桩;图E为栽桩后螺钉稍低于骨平面;图F为假体安装完成
Figure 3 Intraoperative photographs of the right knee. A is intraoperative exposure image, showing severe wear of the medial femoral condyle and a medial tibial plateau defect; B and C are intraoperative views demonstrating the bone defect of the medial tibial plateau; D shows that screws were placed as reinforcement at the site of the tibial bone defect; E shows that the screws are slightly below the articular surface after placement; F is the final view after prosthetic component implantation
图4 右膝术后X线。图A为下肢全长片显示下肢力线恢复良好;图B为右膝正侧位片,示骨水泥界面存在透亮线(白色箭头)
Figure 4 Postoperative radiographs of the right knee. A is full-length radiograph of the lower extremities at anteroposterior view, showing satisfactory restoration of lower limb alignment; B is radiograph of the right knee at anteroposterior and lateral view, showing radiolucent lines at the bone–cement interface (white arrows)
表1 患者一般资料
Table 1 General patient data
表2 两组术前、术后KSS和KSS功能评分(
±s)
Table 2 KSS score and KSS function score before and after surgery in two groups
表3 两组术前、术后WOMAC评分(
±s)
Table 3 WOMAC score before and after surgery in two groups
图5 末次随访大体像显示下肢力线恢复良好,膝关节屈伸活动度满意。图A示仰卧屈膝位膝关节屈曲活动度恢复满意;图B示站立位力线恢复良好;图C示负重屈曲位膝关节屈曲活动度恢复良好
Figure 5 Clinical photographs at the latest follow-up, showing satisfactory restoration of lower limb alignment and knee range of motion. A shows knee flexion range of motion in the supine position; B shows good limb alignment in the standing position; C shows good knee flexion recovery in the weight-bearing flexed position
表4 两组术前术后TFA[°,(
±s)]
Table 4 TFA before and after surgery in two groups
图6 末次随访X线片资料。A为双下肢全长片,可见术后TFA(股胫角)恢复良好;B为右膝术后20个月正侧位X线片,示胫骨平台骨缺损处骨水泥界面有透亮线存在,透亮线(白色箭头)与术后比较无变化;C为左膝术后16个月正侧位X线片,示左膝骨水泥螺钉重建胫骨缺损,骨水泥界面无透亮线
Figure 6 Radiographic data at the latest follow-up. A is full-length of both lower extremities at anteroposterior view, showing satisfactory restoration of postoperative TFA (femorotibial angle); B is anteroposterior and lateral view of the right knee 20 months after surgery, revealing a radiolucent line at the bone-cement interface in the region of tibial plateau bone defect reconstructed with bone cement, and the radiolucent line (white arrow) showed no progression compared with the immediate postoperative radiograph; C is anteroposterior and lateral view of the left knee 16 months after surgery, demonstrating reconstruction of the tibial bone defect using bone cement combined with screws, with no radiolucent line at the bone-cement interface
表5 术后临床评分及下肢力线等效性检验(
±s)
Table 5 Equivalence test of postoperative clinical scores and lower limb alignment
[1]
Xu J, Wang J, Zhao H. The prevalence of kashin-beck disease in China: a systematic review and meta-analysis[J]. Biol Trace Elem Res, 2023, 201(7): 3175-3184.
[2]
Jin ZK, Yang Y, Xu CX, et al. Outcomes of total knee arthroplasty in the adult Kashin-Beck disease with severe osteoarthritis[J]. Int Orthop, 2019, 43(2): 323-331.
[3]
Zhang L, Li H, Bai L, et al. Patients with Kashin-Beck disease obtained lower functional activities but better satisfaction than patients with osteoarthritis after total knee arthroplasty: a retrospective study[J]. Clin Interv Aging, 2022, 17: 1657-1662.
[4]
Sun H, Lai Y, Ding Z, et al. The long-term efficacy of total knee arthroplasty on end-stage Kashin-Beck disease of the knee in highland Tibetan areas patients: a retrospective study with 10-year follow-up[J]. Orthop Surg, 2024, 16(6): 1300-1307.
[5]
Liu HM, Wang YF, Wu JM, et al. A comparative study of clinical effect of total knee arthroplasty in the treatment of primary osteoarthritis and osteoarthritis of Kashin-Beck disease[J]. Int Orthop, 2020, 44(9): 1719-1726.
[6]
Dewidar AA, Mesregah MK, Mesriga MM, et al. Autogenous structural bone graft reconstruction of ≥ 10-mm-deep uncontained medial proximal tibial defects in primary total knee arthroplasty[J/OL]. J Orthop Traumatol, 2024, 25(1): 22. DOI: 10.1186/s10195-024-00762-6.
[7]
Insall JN, Dorr LD, Scott RD, et al. Rationale of the Knee Society clinical rating system[J]. Clin Orthop Relat Res, 1989, 248: 13-14.
[8]
Bellamy N, Buchanan WW, Goldsmith CH, et al. Validation study of WOMAC: a health status instrument for measuring clinically important patient relevant outcomes to antirheumatic drug therapy in patients with osteoarthritis of the hip or knee[J]. J Rheumatol, 1988, 15(12): 1833-1840.
[9]
Lizaur-Utrilla A, Gonzalez-Parreño S, Martinez-Mendez D, et al. Minimal clinically important differences and substantial clinical benefits for Knee Society Scores[J]. Knee Surg Sports Traumatol Arthrosc, 2020, 28(5): 1473-1478.
[10]
Tubach F, Ravaud P, Baron G, et al. Evaluation of clinically relevant changes in patient reported outcomes in knee and hip osteoarthritis: the minimal clinically important improvement[J]. Ann Rheum Dis, 2005, 64(1): 29-33.
[11]
Escobar A, Quintana JM, Bilbao A, et al. Responsiveness and clinically important differences for the WOMAC and SF-36 after total knee replacement[J]. Osteoarthr Cartil, 2007, 15(3): 273-280.
[12]
Bonner TJ, Eardley WGP, Patterson P, et al. The effect of post-operative mechanical axis alignment on the survival of primary total knee replacements after a follow-up of 15 years[J]. J Bone Joint Surg Br, 2011, 93-B(9): 1217-1222.
[13]
Completo A, Simões JA, Fonseca F, et al. The influence of different tibial stem designs in load sharing and stability at the cement–bone interface in revision TKA[J]. Knee, 2008, 15(3): 227-232.
[14]
Aggarwal AK, Baburaj V. Managing bone defects in primary total knee arthroplasty: options and current trends[J]. Musculoskelet Surg, 2021, 105(1): 31-38.
[15]
Freeman MA, Bradley GW, Revell PA. Observations upon the interface between bone and polymethyl methacrylate cement[J]. J Bone Jt Surg Br, 1982, 64-B(4): 489-493.
[16]
Ritter MA. Screw and cement fixation of large defects in total knee arthroplasty[J]. J Arthroplasty, 1986, 1(2): 125-129.
[17]
Chen F, Krackow KA. Management of tibial defects in total knee arthroplasty a biomechanical study[J/OL]. Clin Orthop Relat Res, 1994, 305: 249-257. DOI: 10.1097/00003086-199408000-00031.
[18]
Özcan Ö. Bone cement with screw augmentation technique for the management of moderate tibial bone defects in primary knee arthroplasty patients with high body mass index[J]. Jt Dis Relat Surg, 2021, 32(1): 28-34.
[19]
Liu C, Li J, Sun C, et al. Difference between screw cement filling and adequate osteotomy with thick liner for primary total knee arthroplasty in patients with rand IIb tibial defects[J]. J Arthroplasty, 2023, 38(8): 1510-1515.
[20]
Brand MG, Daley RJ, Ewald FC, et al. Tibial tray augmentation with modular metal wedges for tibial bone stock deficiency[J]. Clin Orthop Relat Res, 1989, 248: 71-79.
[21]
Alasaad H, Ibrahim J. Primary total knee arthroplasty in patients with a significant bone defect in the medial tibial plateau: Case series and literature review[J/OL]. Int J Surg Case Rep, 2023, 110: 108779. DOI: 10.1016/j.ijscr.2023.108779.
[22]
Gaudin G, Butcher C, Lustig S, et al. Screw and cement augmentation of tibial defects in primary total knee arthroplasty: satisfactory midterm outcomes[J]. J ISAKOS, 2018, 3(3): 134-139.
[23]
Lotke PA, Wong RY, Ecker ML. The use of methyl methacrylate in primary total knee replacements with large tibial defects[J/OL]. Clin Orthop Relat Res, 1991, 270: 288-294. DOI: 10.1097/00003086-199109000-00038.
[24]
Khan MW, Rajput IM, Qamar J, et al. Biological reconstruction of posteromedial tibial defect with autogenous bone graft in complex knee arthroplasty[J]. Indian J Orthop, 2023, 57(6): 856-862.
[25]
Ryu JJ, Kim YH, Choi CH. The additional tibial stem extension is not mandatory for the stability of 5 mm metal block augmented tibial prosthesis construct in primary total knee arthroplasty: 5-year minimum follow-up results[J/OL]. Knee Surg Relat Res, 2023, 35(1): 5. DOI: 10.1186/s43019-023-00174-6.
