中华关节外科杂志(电子版) ›› 2025, Vol. 19 ›› Issue (06) : 761 -766. doi: 10.3877/cma.j.issn.1674-134X.2025.06.017

临床经验

3D打印钛金属骨小梁臼杯在髋臼发育不良的应用
林鑫欣, 秦豪, 杨克勤, 甘锋平, 张其标, 罗翔()
  1. 537100 贵港市人民医院骨科
  • 收稿日期:2025-03-31 出版日期:2025-12-01
  • 通信作者: 罗翔
  • 基金资助:
    贵港市科学技术项目(贵科攻2300031)

Application of three-dimensional printed titanium metal trabecular acetabular cups in hip dysplasia

Xinxin Lin, Hao Qin, Keqin Yang, Fengping Gan, Qibiao Zhang, Xiang Luo()

  1. Department of Orthopedics, Guigang People’s Hospital, Guigang 537100, China
  • Received:2025-03-31 Published:2025-12-01
  • Corresponding author: Xiang Luo
引用本文:

林鑫欣, 秦豪, 杨克勤, 甘锋平, 张其标, 罗翔. 3D打印钛金属骨小梁臼杯在髋臼发育不良的应用[J/OL]. 中华关节外科杂志(电子版), 2025, 19(06): 761-766.

Xinxin Lin, Hao Qin, Keqin Yang, Fengping Gan, Qibiao Zhang, Xiang Luo. Application of three-dimensional printed titanium metal trabecular acetabular cups in hip dysplasia[J/OL]. Chinese Journal of Joint Surgery(Electronic Edition), 2025, 19(06): 761-766.

目的

探讨3D打印多孔钛金属骨小梁臼杯与传统生物固定臼杯在Ⅰ/Ⅱ型髋臼发育不良患者全髋关节置换术(THA)中的疗效。

方法

本研究为回顾性队列研究,纳入2021年9月至2023年9月期间于贵港市人民医院接受THA的70例Ⅰ/Ⅱ型髋臼发育不良患者作为研究对象。根据假体类型差异进行分组设计:对照组(n=35)采用生物型髋臼假体完成THA,观察组(n=35)则应用3D打印技术制备的多孔钛金属骨小梁臼杯实施THA。观察2组患者随访时间、假体存活率、视觉模拟疼痛评分(VAS)、Harris髋关节功能评分、假体固定效果和安全性,比较两组的上述指标结果。计量资料组间比较采用独立样本t检验,组内比较采用配对t检验,多个时间点的纵向数据,采用重复测量方差分析,计数资料组间比较采用卡方检验或Fisher确切概率法。采用Mann-Whitney U检验(非参数检验)比较两组的中位随访时间,使用log-rank检验进行生存曲线的组间比较。

结果

两组间VAS差异无统计学意义(F=0.547,P>0.05);两组组内VAS评分3个时间点差异有统计学意义(对照组F=386.724、观察组F=412.159,均为P<0.001);两组交互效应差异有统计学意义(F=4.316,P=0.014)。两组间Harris评分差异存在统计学意义(F=14.582,P<0.05),3个时间点组内的Harris评分差异存在统计学意义(对照组F=387.624、观察组F=425.817,均为P<0.05),交互效应差异存在统计学意义(F=5.217,P<0.05)。多变量分析显示2组患者术前Harris评分差异无统计学意义(t=0.403,P>0.05),术后3、6个月时观察组Harris评分均高于对照组(t=3.809、4.521,均为P<0.05)。两组间随访时长差异无统计学意义(P>0.05),观察组假体存活率100.0%,优于对照组的97.1% [log-rank检验风险比(HR)=0.314,95%置信区间(CI)(0.013,7.892),P>0.05]。

结论

3D打印多孔钛金属骨小梁臼杯能够在一定程度上改善Ⅰ/Ⅱ型髋臼发育不良患者THA中的临床效果,值得临床推广应用。

Objective

To explore the efficacy of three dimentional (3D) -printed porous titanium trabecular acetabular cups and traditional biological fixation acetabular cups in total hip arthroplasty (THA) for patients with type Ⅰ/Ⅱ acetabular dysplasia.

Methods

This retrospective cohort study included 70 patients with type I/II acetabular dysplasia who underwent THA at Guigang People's Hospital from September 2021 to September 2023. Patients were divided into two groups based on the type of prosthesis: the control group (n=35) received THA with a biological acetabular prosthesis, and the observation group (n=35) received THA with a 3D-printed porous titanium trabecular acetabular cup. The follow-up time, prosthesis survival rate, visual analogue scale (VAS) pain score, Harris hip score, prosthesis fixation effect, and safety were observed in both groups. The results of the above indicators were compared between the two groups. Independent sample t test was used for comparisons between groups for measurement data, paired ttest was used for comparisons within groups, and repeated measures ANOVA for the data at multiple time points. Chi square test or Fisher’s exact probability method were used for comparisons between groups for count data. The Mann-Whitney U test (non-parametric test) was used to compare the follow-up time between the two groups, and the log-rank test was used for comparison of survival curves between groups.

Results

There was no statistically significant difference in VAS between the two groups (F=0.547, P>0.05), and there were statistically significant differences in both groups at three time points(control group F=386.724, observation group F=412.159, both P<0.001), while the difference in interaction effect of VAS score was also statistically significant ( interaction F=4.316, P=0.014). As for Harris scores, there was a statistically significant difference between the two groups (F=14.582, P<0.05), and statistically significant differences within both groups among the three time points (control group F=387.624, observation group F=425.817, both P<0.05). There was a statistically significant difference in interaction effect of the two groups (F=5.217, P<0.05). Multivariate analysis showed no statistically significant difference in Harris scores before operation between the two groups (t=0.403, P>0.05), but the observation group had higher Harris scores than the control group at three and six months after surgery (t=3.809, 4.521, both P<0.05). There was no statistically significant difference in follow-up duration between the two groups (P>0.05). The prosthesis survival rate of the observation group (100.0%) was better than the control group (97.1%) [ log-rank test hazard ratio (HR)=0.314, 95% confidence interval (CI) (0.013, 7.892), P<0.05].

Conclusion

3D-printed porous titanium trabecular acetabular cups can improve the clinical outcomes of THA in patients with type Ⅰ/Ⅱ acetabular dysplasia to a certain extent and are worthy of clinical promotion and application.

表1 两组患者一般资料比较
Table 1 Comparison of general data between the two groups
表2 两组手术前后VAS比较(±s
Table 2 Comparison of VAS scores between the two groups before and after surgery
表3 两组患者手术前后Harris评分比较(±s
Table 3 Comparison of Harris scores between the two groups before and after surgery
图1 标准化3D打印多孔钛合金髋臼杯关节置换术。图A为术前骨盆正位X线片,示双侧髋关节发育不良;图B为右髋正侧位X线片,示右侧Ⅱ型髋臼发育不良,合并骨关节炎;图C为术后1个月骨盆正位X线片,图D为右髋关节正侧位X线片,示右侧全髋置换术后,旋转中心复位良好;图G为术后6个月骨盆正位X线片,示双侧全髋置换后人工假体稳定,骨长入良好;图H为3D打印多孔钛合金髋臼杯
Figure 1 Images of the patient undergoing standardized 3D printed porous titanium alloy acetabular cup arthroplasty. A is the anteroposterior X-ray image of the pelvis before operation, showing bilateral developmental dysplasia of the hip; B is the anteroposterior and lateral X-ray image of the right hip, showing typeⅡ acetabular dysplasia of the right hip, combined with osteoarthritis; C is the anteroposterior X-ray image of the pelvis at one month after surgery, D is the anteroposterior and lateral X-ray image of the right hip, showing the right hip with good reduction of the rotational center after total hip arthroplasty; G is the anteroposterior X-ray image of the pelvis at six months after surgery, showing stable prostheses in bilateral total hip arthroplasty and good bone ingrowth; H is the 3D-printed porous titanium alloy acetabular cup
[1]
Zhao Z, Fan C, Wang S, et al. Single-nucleus RNA and multiomics in situ pairwise sequencing reveals cellular heterogeneity of the abnormal ligamentum teres in patients with developmental dysplasia of the hip[J/OL]. Heliyon, 2024, 10(6): e27803. DOI: 10.1016/j.heliyon.2024.e27803.
[2]
Gaddis JM, de Souza R, Montanez B, et al. Hip preservation surgery in patients with femoroacetabular impingement syndrome and acetabular dysplasia improves functional measures and pain catastrophizing [J/OL]. Cureus, 2024, 16(1): e52461. DOI: 10.7759/cureus.52461.
[3]
张衡, 周宇凡, 李博闻, 等. CroweⅢ型髋关节发育不良人工全髋关节置换髋臼解剖重建与非解剖重建髋关节生物力学有限元分析[J]. 中国骨伤, 2024, 37(05): 505-515.
[4]
Kawano T, Nankaku M, Murao M, et al. Recovery of muscle atrophy and fatty infiltration in patients with acetabular dysplasia after total hip arthroplasty [J/OL]. J Am Acad Orthop Surg, 2022, 30(3): e317-e326. DOI: 10.5435/JAAOS-D-21-00156.
[5]
商广前. 3D打印钛合金骨小梁金属臼杯用于髋关节翻修术的临床效果评价[D]. 青岛大学, 2022.
[6]
赵旻暐, 耿霄, 褚红玲, 等. 膝关节置换3D打印个性化手术工具临床应用专家共识计划书 [J/OL]. 中华关节外科杂志(电子版), 2023, 17(3): 308-310.
[7]
Wang NK, Shen SH, Chen BPJ, et al. Definition of hip displacement and dislocation by acetabular dysplasia in children with cerebral palsy [J]. J Child Orthop, 2023, 17(4): 315-321.
[8]
Jaber A, Bangert Y, Gather K, et al. Functional outcome and athletic level after arthroscopic repair followed by triple pelvic osteotomy in patients with labral tears resulting from acetabular dysplasia [J]. Orthopadie, 2023, 52(9): 767-772.
[9]
赵春鹏, 肖鸿鹄, 曹奇勇, 等. 个性化3D打印补块修复髋臼大范围骨缺损在髋臼骨折延期人工髋关节置换术中的初步应用[J]. 中华创伤骨科杂志, 2023, 25(6): 470-477.
[10]
丁育健, 冯德宏, 王凌, 等. 髋关节翻修术中应用数字设计3D打印定制带翼臼杯重建髋臼严重骨缺损[J]. 中华骨科杂志, 2023, 43(2): 97-103.
[11]
付君, 倪明, 陈继营, 等. 个性化3D打印多孔钛合金加强块重建重度髋臼骨缺损的早期临床疗效研究[J]. 中华骨与关节外科杂志, 2018, 11(6): 401-407.
