腓骨形态与膝关节骨关节炎相关性的影像学研究

doi:10.3877/cma.j.issn.1674-134X.2026.04.008

目的

探索不同严重程度膝骨关节炎患者腓骨形态的差异及作用，以及腓骨形态在不同畸形膝骨关节炎中的差异及作用。

方法

回顾性分析大理白族自治州人民医院2021年1月至2023年10月就诊患者，纳入年满18岁有标准的下肢站立位全长片的符合膝骨关节炎诊断患者，排除存在下肢外伤史或手术史、下肢骨骼发育不良或骨病的患者。最终纳入269例患者（447膝），男75例、女194例，年龄18～86岁。使用Kellgren-Lawrence评分（K-L）评估膝骨关节炎的影像学严重程度。影像学测量指标包括：髋膝踝角、腓骨整体弯曲、近端腓骨弯曲、远端腓骨弯曲、腓骨胫骨距离和胫腓骨间隙面积。单因素分析膝关节骨关节炎发生发展中腓骨形态指标的差异，采用logistic回归分析各腓骨形态指标在膝骨关节炎发生发展中的作用。

结果

随着K-L分级的增加腓骨整体弯曲度、近端腓骨弯曲、远端腓骨弯曲、腓骨胫骨距离和胫腓骨间隙面积在各组之间差异没有统计学意义（均为P＞0.05）。外翻膝骨关节炎中的腓骨近端和远端弯曲程度均大于内翻膝骨关节炎，差异具有统计学意义（t=1.985、-3.642，均为P＜0.05），而腓骨整体弯曲度、腓骨胫骨距离和胫腓骨间隙面积在各组之间差异没有统计学意义（均为P＞0.05）。二分类logistic回归分析显示近端腓骨弯曲［比值比（OR）=1.312，95%置信区间（CI）（1.071，1.607），P=0.009］和远端腓骨弯曲［OR=0.712，95% CI（0.589，0.861），P＜0.001］差异有统计学意义。

结论

本研究发现腓骨形态影像学参数在膝关节骨关节炎严重程度分组中无明显差异。但是发现了腓骨形态影像学参数近端腓骨弯曲和远端腓骨弯曲在内翻和外翻膝骨关节炎中存在差异，近端腓骨弯曲可能是内翻畸形膝骨关节炎的危险因素，而远端腓骨弯曲可能是内翻畸形膝关节骨关节炎的保护因素。

关键词: 膝关节, 骨关节炎, 腓骨, 影像学

Objective

To explore the differences and roles of fibular morphology in patients with knee osteoarthritis of different severity levels, as well as in knee osteoarthritis with various deformities.

Methods

A retrospective analysis was conducted on patients who visited the Dali Bai Autonomous Prefecture People’s Hospital from January 2021 to October 2023. Inclusion criteria: patients aged ≥18 years, with standard standing full-length radiographs of the lower extremities and diagnosis of knee osteoarthritis. Exclusion criteria: history of lower limb trauma or surgery, lower limb skeletal dysplasia or bone diseases. A total of 269 patients (447 knees) were finally included, comprising 75 males and 194 females, with age ranging from 18 to 86 years. The Kellgren-Lawrence (K-L) grading system was used to assess the radiological severity of knee osteoarthritis. Radiological measurement indicators included: hip-knee-ankle angle, total fibular curvature, proximal fibular curvature, distal fibular curvature, fibular-tibial distance, and tibiolfibular interosseous space area. Univariate analysis was first performed to evaluate the differences in fibular morphological indicators in the occurrence and progression of knee osteoarthritis, followed by logistic analysis to determine the role of each fibular morphological indicator in the occurrence and progression of knee osteoarthritis.

Results

With the increase in K-L grading, no significant differences were observed in overall total fibular curvature, proximal fibular curvature, distal fibular curvature, fibular-tibial distance, and tibiolfibular interosseous space area among the groups (P>0.05). The proximal fibular curvature and distal fibular curvature in the varus knee osteoarthritis group were both greater than those in the valgus knee osteoarthritis group, with statistically significant differences (t=1.985, -3.642, both P<0.05), while overall total fibular curvature, fibular-tibial distance, and tibiolfibular interosseous space area showed no significant differences among the groups (all P>0.05). Binary logistic regression analysis indicated that differences in proximal fibular curvature [odds ratio (OR)=1.312, 95% confidence interval (CI) (1.071, 1.607) , P=0.009] and distal fibular curvature (OR=0.712, 95% CI (0.589, 0.861), P<0.001) were statistically significant.

Conclusions

This study found no statistically significant differences in fibular morphological imaging parameters between groups of different severity of knee osteoarthritis. However, differences were observed in the proximal and distal fibular curvatures between varus and valgus knee osteoarthritis. Proximal fibular curvature may be a risk factor for knee osteoarthritis in varus deformity, Distal fibular curvature may also be a protective factor for varus deformity knee osteoarthritis.

Key words: Knee joint, Osteoarthritis, Fibula, Radiology

图1 HKA（髋膝踝角）和FTD（腓骨胫骨距离）测量方法注：HKA为股骨机械轴（A线）和胫骨机械轴（B线）之间的夹角，股骨机械轴定义为连接股骨头中心（由最佳拟合圆确定）和股骨远端最宽处的中点的线，胫骨机械轴定义为膝关节中心和踝关节中心的连线；FTD为腓骨髓腔中点（C点）与胫骨解剖轴（D线）的垂直距离（红色E线）

Figure 1 Measurement methods of HKA (hip-knee-ankle angle) and FTD (fibular tibial distance) Note: HKA is the angle between the mechanical axis of the femur (line A) and the mechanical axis of the tibia (line B). The mechanical axis of the femur is defined as the line connecting the center of the femoral head (determined by the best-fit circle) and the midpoint of the widest part of the distal femur. The mechanical axis of the tibia is defined as the line connecting the center of the knee joint and the center of the ankle joint. FTD is the perpendicular distance (red line E) from the midpoint of the fibular medullary cavity (point C) to the anatomical axis of the tibia (line D)

图2 TFC（腓骨整体弯曲度）、PFC（近端腓骨弯曲度）和DFC（远端腓骨弯曲度）的测量方法注：TFC为腓骨近端髓腔中心线（F线）和腓骨远端髓腔中心线（G线）夹角的内侧角；PFC为腓骨近端髓腔中心线（H线）和中间髓腔中心线（I线）夹角的内侧角；DFC为腓骨远端髓腔中心线（J线）和中间髓腔中心线（I线）夹角的外侧角

Figure 2 Measurement methods of TFC (total fibular curvature), PFC (proximal fibular curvature) and DFC (distal fibular curvature) Note: TFC is the medial angle between the centerline of the proximal fibular medullary cavity (line F) and the centerline of the distal fibular medullary cavity (line G); PFC is the medial angle between the centerline of the proximal fibular medullary cavity (line H) and the centerline of the middle medullary cavity (line I); DFC is the lateral angle between the centerline of the distal fibular medullary cavity (line J) and the centerline of the middle medullary cavity (line I)

图3 TFISA（胫腓骨间隙面积）的测量方法注：TFISA为胫腓骨全长正位X线片上，胫骨外侧缘和腓骨内侧缘之间空间的面积（红色部分）

Figure 3 Measurement method of TFISA (tibiol fibular interosseous space area) Note: TFISA is the area of the space between the lateral border of the tibia and the medial border of the fibula on the anteroposterior full-length radiograph of the tibia and fibula (indicated in red)

表1 不同程度内翻膝OA的影像学测量结果（

x ¯

±s）

Table 1 Radiographic measurement results of different degrees of varus knee OA

K-L分级	例数 Number of cases	TFC（°）	PFC（°）	DFC（°）	FTD（mm）	TFISA（cm²）
Ⅰ	106	177.94±0.17	177.70±0.14	177.28±0.14	31.60±0.40	46.02±1.10
Ⅱ	67	177.80±0.20	177.24±0.17	177.08±0.21	32.50±0.50	46.25±1.17
Ⅲ	68	177.74±0.24	177.69±0.19	177.29±0.15	32.50±0.50	46.64±1.41
Ⅳ	133	177.57±0.16	177.27±0.16	177.03±0.15	32.20±0.40	43.62±0.93
t值		0.496	0.800	0.615	0.270	0.142
P值		＞0.05	＞0.05	＞0.05	＞0.05	＞0.05

表1 不同程度内翻膝OA的影像学测量结果（

x ¯

±s）

Table 1 Radiographic measurement results of different degrees of varus knee OA

K-L分级	例数 Number of cases	TFC（°）	PFC（°）	DFC（°）	FTD（mm）	TFISA（cm²）
Ⅰ	106	177.94±0.17	177.70±0.14	177.28±0.14	31.60±0.40	46.02±1.10
Ⅱ	67	177.80±0.20	177.24±0.17	177.08±0.21	32.50±0.50	46.25±1.17
Ⅲ	68	177.74±0.24	177.69±0.19	177.29±0.15	32.50±0.50	46.64±1.41
Ⅳ	133	177.57±0.16	177.27±0.16	177.03±0.15	32.20±0.40	43.62±0.93
t值		0.496	0.800	0.615	0.270	0.142
P值		＞0.05	＞0.05	＞0.05	＞0.05	＞0.05

表2 内翻和外翻膝关节OA的影像学结果（

x ¯

±s）

Table 2 Radiographic findings of varus and valgus knee OA

类型 Types	例数 Number of cases	TFC（°）	PFC（°）	DFC（°）	FTD（mm）	TFISA（cm²）
膝内翻 Genu varum	374	177.94±0.17	177.46±0.08	177.16±0.09	32.20±0.20	45.32±0.56
膝外翻 Genu valgum	73	177.63±0.11	177.85±0.18	177.34±0.21	31.70±0.50	46.88±1.35
t值		-1.765	1.985	-3.642	-0.885	1.354
P值		＞0.05	＜0.05	＜0.001	＞0.05	＞0.05

表2 内翻和外翻膝关节OA的影像学结果（

x ¯

±s）

Table 2 Radiographic findings of varus and valgus knee OA

类型 Types	例数 Number of cases	TFC（°）	PFC（°）	DFC（°）	FTD（mm）	TFISA（cm²）
膝内翻 Genu varum	374	177.94±0.17	177.46±0.08	177.16±0.09	32.20±0.20	45.32±0.56
膝外翻 Genu valgum	73	177.63±0.11	177.85±0.18	177.34±0.21	31.70±0.50	46.88±1.35
t值		-1.765	1.985	-3.642	-0.885	1.354
P值		＞0.05	＜0.05	＜0.001	＞0.05	＞0.05

表3 内翻和外翻膝OA的logistic回归结果

Table 3 Logistic regression results for varus and valgus knee OA

相关因素 Related factors	回归系数	标准误	Wald χ²值	P值	OR（95% CI）
PFC	0.271	0.104	6.867	0.009	1.312（1.071，1.607）
DFC	-0.340	0.097	12.265	＜0.001	0.712（0.589，0.861）

表3 内翻和外翻膝OA的logistic回归结果

Table 3 Logistic regression results for varus and valgus knee OA

相关因素 Related factors	回归系数	标准误	Wald χ²值	P值	OR（95% CI）
PFC	0.271	0.104	6.867	0.009	1.312（1.071，1.607）
DFC	-0.340	0.097	12.265	＜0.001	0.712（0.589，0.861）

［1］	Molnar V, Matišić V, Kodvanj I, et al. Cytokines and chemokines involved in osteoarthritis pathogenesis［J/OL］. Int J Mol Sci, 2021, 22（17）: 9208. DOI: 10.3390/ijms22179208.
［2］	Katz JN, Arant KR, Loeser RF. Diagnosis and treatment of hip and knee osteoarthritis: a review［J/OL］. JAMA, 2021, 325（6）: 568－578. DOI: 10.1001/jama.2020.22171.
［3］	王旭东, 张紫机. 骨关节炎危险因素与发病机制的研究进展［J/OL］. 中华关节外科杂志（电子版）, 2022, 16（6）: 745－755.
［4］	中华医学会骨科学分会关节外科学组. 骨关节炎诊疗指南（2018年版）［J］. 中华骨科杂志, 2018, 38（12）: 705－715.
［5］	Murphy L, Schwartz TA, Helmick CG, et al. Lifetime risk of symptomatic knee osteoarthritis［J］. Arthritis Rheum, 2008, 59（9）: 1207－1213.
［6］	薛庆云, 王坤正, 裴福兴, 等. 中国40岁以上人群原发性骨关节炎患病状况调查［J］. 中华骨科杂志, 2015, 35（12）: 1206－1212.
［7］	Mistry D, Chandratreya A, Lee P. An update on unloading knee braces in the treatment of unicompartmental knee osteoarthritis from the last 10 years: a literature review［J］. Surg J, 2018, 4（3）: e110－e118.
［8］	Wang J, Lv HZ, Chen W, et al. Anatomical adaptation of fibula and its mechanism of proximal partial fibulectomy associated with medial compartment knee osteoarthritis［J］. Orthop Surg, 2019, 11（2）: 204－211.
［9］	Sharma L, Song J, Dunlop D, et al. Varus and valgus alignment and incident and progressive knee osteoarthritis［J］. Ann Rheum Dis, 2010, 69（11）: 1940－1945.
［10］	Dong T, Chen W, Zhang F, et al. Radiographic measures of settlement phenomenon in patients with medial compartment knee osteoarthritis［J］. Clin Rheumatol, 2016, 35（6）: 1573－1578.
［11］	Wang TR, Wang HD, Chen W, et al. Proximal fibular osteotomy alleviates medial compartment knee osteoarthritis in a mouse model［J］. Int Orthop, 2020, 44（6）: 1107－1113.
［12］	王娟, 于滕波, 郑占乐, 等. 膝关节骨关节炎病理机制的研究进展［J］. 河北医科大学学报, 2019, 40（10）: 1237－1238.
［13］	Wang X, Wei L, Lv Z, et al. Proximal fibular osteotomy: a new surgery for pain relief and improvement of joint function in patients with knee osteoarthritis［J］. J Int Med Res, 2017, 45（1）: 282－289.
［14］	Utomo DN, Mahyudin F, Wijaya AM, et al. Proximal fibula osteotomy as an alternative to TKA and HTO in late-stage varus type of knee osteoarthritis［J］. J Orthop, 2018, 15（3）: 858－861.
［15］	Ahmed M, Bux M, Kumar M, et al. Proximal fibular osteotomy in the management of osteoarthritis of medial compartment of knee joint［J/OL］. Cureus, 2020, 12（6）: e8481. DOI: 10.7759/cureus.8481.
［16］	Atlıhan D, Günaydın F, Muslu DC. Effects of proximal fibular partial excision on medial compartment knee osteoarthritis［J］. Int Orthop, 2022, 46（10）: 2251－2256.
［17］	Wang J, Chen W, Hou ZY, et al. Law of dynamic deformation of bone［J］. Chin Med J, 2019, 132（21）: 2636－2637.
［18］	Yang ZY, Chen W, Li CX, et al. Medial compartment decompression by fibular osteotomy to treat medial compartment knee osteoarthritis: a pilot study［J/OL］. Orthopedics, 2015, 38（12）: e1110－e1114. DOI: 10.3928/01477447－20151120-08.
［19］	马温儒, 丁磊, 孙胜男, 等. 腓骨头高度与内翻型膝关节骨关节炎的发病及严重程度的关系［J］. 中华骨科杂志, 2021, 41（14）: 985－991.
［20］	范贤成, 马剑雄, 王颖, 等. 膝关节外翻畸形来源的研究进展［J］. 中华骨科杂志, 2023, 43（13）: 915－921.
［21］	Deng XT, Hu HZ, Zhu J, et al. Associations between periosteal reaction of proximal tibial and medial compartment knee osteoarthritis［J］. Orthop Surg, 2021, 13（4）: 1327－1335.
［22］	Bozkurt M, Yilmaz E, Atlihan D, et al. The proximal tibiofibular joint: an anatomic study［J］. Clin Orthop Relat Res, 2003, 406: 136－140.
［23］	Jiang WB, Sun SZ, Li C, et al. Anatomical basis of the support of Fibula to tibial plateau and its clinical significance［J/OL］. J Orthop Surg Res, 2021, 16（1）: 346. DOI: 10.1186/s13018－021－02500－8.
［24］	Zhao Y, Zhu Z, Chang J, et al. Predictive value of the morphology of proximal tibiofibular joint for total knee replacement in patients with knee osteoarthritis［J］. J Orthop Res, 2021, 39（6）: 1289－1296.
［25］	Chang J, Zhu Z, Han W, et al. The morphology of proximal tibiofibular joint （PTFJ） predicts incident radiographic osteoarthritis: data from Osteoarthritis Initiative［J］. Osteoarthr Cartil, 2020, 28（2）: 208－214.
［26］	Chang J, Chen T, Yan Y, et al. Associations between the morphological parameters of proximal tibiofibular joint （PTFJ）and changes in tibiofemoral joint structures in patients with knee osteoarthritis［J/OL］. Arthritis Res Ther, 2022, 24（1）: 34. DOI: 10.1186/s13075－022－02719－8.
［27］	Huang C, Chen S, Liu D, et al. Association between the inclination angle of the proximal tibiofibular joint surface and medial compartment knee osteoarthritis［J］. Ann Palliat Med, 2021, 10（8）: 8753－8761.
［28］	Panyarachun P, Angthong C, Jindasakchai P, et al. Abnormal foot pressure in older adults with knee osteoarthritis: a systematic review［J］. Eur Rev Med Pharmacol Sci, 2022, 26（17）: 6236－6241.
［29］	Almeheyawi RN, Bricca A, Riskowski JL, et al. Foot characteristics and mechanics in individuals with knee osteoarthritis: systematic review and meta-analysis［J/OL］. J Foot Ankle Res, 2021, 14（1）: 24. DOI: 10.1186/s13047－021－00462－y.
［30］	Levinger P, Menz HB, Morrow AD, et al. Foot kinematics in people with medial compartment knee osteoarthritis［J］. Rheumatology（Oxford）, 2012, 51（12）: 2191－2198.
［31］	Tadano S, Takeda R, Sasaki K, et al. Gait characterization for osteoarthritis patients using wearable gait sensors（H-Gait systems）［J］. J Biomech, 2016, 49（5）: 684－690.
［32］	Hirschmann MT, Hess S, Behrend H, et al. Phenotyping of hip-knee-ankle angle in young non-osteoarthritic knees provides better understanding of native alignment variability［J］. Knee Surg Sports Traumatol Arthrosc, 2019, 27（5）: 1378－1384.
